# How to File a Square on a Cylinder

Being able to file a square is a core skill of a watchmaker, demonstrating the ability to file a flat and at perpendicular angles.

It has practical uses in the construction of many items. In this example we are filing a square to be used on a winding stem.

For a small piece such as this we will use a cut 6 file.

When you are cutting the cylinder to diameter, try and go to the maximum minimum tolerance on rounded cylinder. e.g. if tolerance is -0.01mm on a 1mm bar, take it to 0.99mm. The reason is that the smaller the bar, the more prominent the chamfer on the edges of the square.

The chamfer will demonstrate your skill at turning and will the by virtue of their thickness whether the square is central to the cylinder.

You also want a chamfered edge as the winding pinion’s inside corners won’t be perfectly sharp.

Using an India stone, take away the chamfer on the edge of the file on the safe edge. This will allow the cutting part of the file to be tight to the edge allowing you to have sharp corners on whatever you’re filing.

Use a filing button of steel or brass to protect the collet and any shoulder

Measure the length with the end of the vernier gauge and then tighten lathe
Mark 90 degree points on the divider on the lathe to ensure that you don’t forget the exact angles.

The first side’s depth (x) can be worked out from the width of the square (y) and the diameter of the bar (z).
x = ((z-y)/2) + y

In this case we’re making a 0.88mm square from a 1.2mm bar.

So;

x = ((1.2-0.88)/2) + 0.88

x = 1.04mm

Add 0.005mm (5 microns) to each side for lapping, 0.01mm total width.

Get a roller and set it at the same hight as the piece. You should try to move it as far away as possible from the piece, this will help you keep the file straight.
Support the piece from underneath with your finger.
Make a few strokes with the file. You can see whether you are cutting straight or not by whether the file marks leave parallel lines on the cylinder. You can adjust the pressure you are putting on the piece accordingly to ensure that you are filing flat.
Never move the roller, as you will not be able to duplicate the same angle that you are filing at if you do.

Measure the piece with a micrometer to see how much you have removed. Be very careful when you’re using the micrometre. Unwind it before trying to move it away, or else you may bend or mark the piece.
To use a micrometer, tighten it until the handle slips. Each of the markers on the vertical part equal 0.5mm. In this case there is zero and then 2 markers, so that makes it 1mm. You then read the horizontal markers to see how far between 1mm and 1.5mm it is. Here it is about 11.5. Each one of these equals 0.01mm.
This makes the current width 1.115mm. So we still have more material to remove.

Draw file to remove the final file marks and remove the last few 100ths of material. Be sure to keep measuring, so that you can know how much pressure to put on the file. Once you have filed one side you can then turn the piece in the lathe using the divider. It’s personal preference whether you turn it 90 degrees or 180 degrees to begin with.
You then file each side until you are 0.01mm above the measurement.

Here we can see that the micrometer is reading 1.05mm. This is the 1.04mm we need plus the 0.01mm extra we are allowing for the final lapping.

You now want to lap the final 0.01mm off. This should usually be enough material to remove all of the file marks.
Set the lathe as a swing tool using centres. The piece should have no play but should be free to move.
Using a piece of brass or other softer material. File the piece of metal that you are going to use to make sure the corners are sharp and the surface is flat.
Put some abrasive paste on the lapping tool. You want horizontal graining across the piece, with all the file marks removed, sharp shoulders and even chamfered edges

The final squared piece

### 2 Responses

1. I am not sure how you would get a 0.88mm square from a 1.2mm bar?

The largest square that would fit inside a circle 1.2mm diameter is just under 0.85mm square, so where does the extra 0.03mm (0.015mm on each side) to take it up to 0.88mm come from?

It seems a small amount, but it is three times greater than the 0.005mm (5 microns) you allowed on each side for lapping.

2. Colin says:

Hi David,
